Adding UltraRadialGauge

Purpose

This topic explains using a code example how to add the UltraRadialGauge™ control to Windows Forms applications.

In this topic

This topic contains the following sections:

Adding UltraRadialGauge to the Windows Forms application

Introduction

The following procedure demonstrates adding the UltraRadialGauge to Windows Forms applications.

Preview

The following is a screenshot of the UltraRadialGauge control.

Adding xamRadialGauge to your Application 1 17 1.png

Requirements

Add the following Infragistics assemblies to your main project:

  • Infragistics.Win.DataVisualization.UltraGauges.dll

  • Infragistics.Win.DataVisualization.Shared.dll

  • Infragistics.Win.Portable.Core.dll

Also, add the following Infragistics namespaces:

In C#:

using Infragistics.Win.DataVisualization;

In VB:

Imports Infragistics.Win.DataVisualization

Overview

Following is a conceptual overview of the process:

1. Adding the UltraRadialGauge control to Windows Forms applications

2. Verifying the results

Steps

The following procedure takes you through the steps necessary for adding the UltraRadialGauge control to a page.

1. Add the UltraRadialGauge control to the page.

The following code demonstrates adding the UltraRadialGauge control with the minimum code and property settings required for display:

In Visual Basic:

Dim radialGauge As New UltraRadialGauge()
  Me.Controls.Add(radialGauge)

In C#:

var radialGauge = new UltraRadialGauge();
this.Controls.Add(radialGauge);

2. Verify the results.

Build and run your project to verify the result. If you have implemented the steps correctly, the displayed UltraRadialGauge should look like the one in the Preview section above.
